Value Collection VNMG332 I22 Carbide Turning Insert Uncoated, 16.6mm Long, 3/8 Inscribed Circle, 1/32 Corner Radius, 35 Diamond VNMG160408K20 – 04154100

Value Collection VNMG332 I22 Carbide Turning Insert Uncoated, 16.6mm Long, 3/8 Inscribed Circle, 1/32 Corner Radius, 35 Diamond VNMG160408K20 – 04154100

  • $18.82
  • $31.37
Availability: In Stock

Value Collection VNMG332 I22 Carbide Turning Insert Uncoated, 16.6mm Long, 3/8" Inscribed Circle, 1/32" Corner Radius, 35 DiamondManufacturer Part #: VNMG160408K20S/N: 04154100UNSPSC: 23242105(Minimum Order Quantity=1, Package Quantity=1)Specifications:ANS

Category:
Share:
payment
Description Reviews (0)

Value Collection VNMG332 I22 Carbide Turning Insert Uncoated, 16.6mm Long, 3/8″ Inscribed Circle, 1/32″ Corner Radius, 35 Diamond

Manufacturer Part #: VNMG160408K20

S/N: 04154100

UNSPSC: 23242105

(Minimum Order Quantity=1, Package Quantity=1)

Specifications:

ANSI Insert Code VNMG332 ISO Insert Code VNMG160408 Relief Angle 0 Insert Style VNMG Corner Radius (Inch) 1/32 Corner Radius (Decimal Inch) 0.0315 Included Angle 35 Manufacturer Grade I22 Coating/Finish Bright/Uncoated Insert Thickness (Inch) 3/16 Insert Thickness (Decimal Inch) 0.1875 Inscribed Circle (Inch) 3/8 Inscribed Circle (Decimal Inch) 0.3752 Insert Material Carbide Insert Shape V – Diamond (Rhombic) 35-Deg Side Clearance Negative Insert Shape Code V Hole Diameter (Decimal Inch) 0.1500 Hole Diameter (Mm) ( – 0 Decimals) 3.81 Insert Holding Method Clamp, Pin Clearance Code N Tolerance Code M Insert Length (mm) 16.60 Primary Workpiece Material Code K, M, N, S Material Grade C2 Chip Breaker G ANSI Size Code 332 ISO Size Code 160408 UNSPSC Code 23242105 Insert Size Code 332
